Guido - Configuration Template Manager

A visual configuration management tool for creating, editing, and validating application settings with intelligent rule-based automation.

Live Demo • Quick Start • Features • Documentation

What is Guido?

Guido is a web-based GUI application that simplifies the management of complex configuration files. Instead of manually editing JSON, YAML, or other config formats, Guido provides:

• Visual editing of configuration fields with validation
• Intelligent rules that automatically enable/disable settings based on conditions
• Template system with reusable configuration schemas
• Multi-format support for JSON, YAML, CSV, .env, .properties, and .txt files

Quick Start

Use the Hosted App

Visit quotentiroler.github.io/Guido to use Guido directly in your browser.

Run Locally

# Clone the repository
git clone https://github.com/quotentiroler/Guido.git
cd Guido

# Install dependencies
npm install

# Start development server
npm run dev

Open http://localhost:5173 in your browser.

Features

🎛️ Visual Configuration Editor

Edit configuration fields through an intuitive UI with:

• Field metadata (descriptions, examples, documentation links)
• Real-time validation (integers, booleans, URLs, regex patterns, enums)
• Checkbox-based field selection for export

🔗 Rule Engine

Define conditional logic that automatically manages field dependencies:

If "Repository" is set to "MongoDb"
Then "MongoDbOptions.ConnectionString" must be set

Rule States:

🤖 MCP Server (AI Integration)

The included MCP (Model Context Protocol) server enables AI assistants like Claude to manage Guido templates programmatically.

Documentation

Template Structure

A .guido.json template consists of:

{
  "name": "My App Settings",
  "fileName": "appsettings.json",
  "version": "1.0.0",
  "description": "Configuration template for My App",
  "owner": "MyOrganization",
  "application": "My App",
  "docs": "https://docs.example.com",
  "command": "docker run myapp:latest",
  "fields": [...],
  "ruleSets": [...]
}

Field Definition

Each field describes a configuration option:

{
  "name": "Database.ConnectionString",
  "value": "Server=localhost;Database=mydb",
  "info": "Connection string for the primary database",
  "example": "Server=localhost;Database=mydb;User=admin",
  "range": "string",
  "link": "https://docs.example.com/connection-strings",
  "checked": true
}

Field Properties:

Range Types:

Rule Definition

Rules define conditional relationships between fields:

{
  "description": "MongoDB requires connection string",
  "conditions": [
    { "name": "Repository", "state": "set_to_value", "value": "MongoDb" }
  ],
  "targets": [
    { "name": "MongoDbOptions.ConnectionString", "state": "set" }
  ]
}

Logic: If the conditions match, then ALL targets are enforced. Conditions combine per the rule's match: all (default, AND - every condition must hold) or any (OR - at least one).

Cardinality Constraints

A ruleset can also declare cardinality constraints over a set of fields (validated against a config, not applied as rules):

{
  "constraints": [
    { "kind": "exactly-one", "fields": ["MongoDb", "SQLite", "Postgres"] }
  ]
}

kind is exactly-one (exactly 1 of the fields set), at-least-one (>= 1), or at-most-one (<= 1). A field counts as set when it is enabled with a non-empty value.

RuleDomain Properties:

Known Limitations

Dynamic Arrays of Complex Objects

Guido cannot describe configuration structures with dynamic arrays of complex objects where users need to add/remove items at runtime. The dot notation flattening (e.g., Plugins.0.Name, Plugins.1.Name) works for fixed-size arrays but not for unbounded collections.

CLI Tools

Validate Templates

npm run validate "path/to/template.guido.json"

Checks for:

• Rule contradictions
• Circular dependencies
• Invalid rule structures
• Field validation issues

Convert JSON Schema to Guido

npm run schema-to-guido "schema.json" -o "output.guido.json" \
  --name "My Template" \
  --version "1.0.0" \
  --owner "MyOrg" \
  --application "My App" \
  --docs "https://docs.example.com"

Convert Guido to JSON Schema

npm run guido-to-schema "template.guido.json" -o "output.schema.json"

Available Scripts

Technology Stack

• Frontend: React 19, TypeScript, Tailwind CSS
• Build: Vite, npm workspaces (monorepo)
• Testing: Vitest
• Deployment: GitHub Pages

Contributing

We welcome contributions! Please see our Contributing Guide for details.

Before contributing, please read our Code of Conduct.

Quick Start for Contributors

# Fork and clone the repo
git clone https://github.com/YOUR_USERNAME/Guido.git
cd Guido

# Install dependencies
npm install

# Run tests
npm test

# Start development server
npm run dev
